Traction Machine FJT-YM01 1350-2000kg

Traction Machine FJT-YM01 1350-2000kg

Rated Load: 1350 - 2000 kg
Speed: 1.0 - 3.0 m/s
Max. Able Load: 6000 kg
Poles: 32
Starts Per Hour: 240
Insulation Class: F
Enclosure Class: IP40
Rating: S5-40%

• Machine low speed operation smooth, with low noise and small vibration.
• Use block type armless brake with high reliability.
• High power factor, with quick response time and high reliability
• Adapt different inverters, position sensors.
• The brake passed 2 million times braking. After the test, its performance is still in specification. Safety is guaranteed.
